1.10 - Uw for Ug=1.0 (warm edge)
3 - gasket system
6 - chamber structure
- 0.91
- 1.10
- B class profiles,
- 6-chamber structure,
- installation depth: 82 mm,
- manufactured using white, brown, caramel, and anthracite core,
- standard device preventing an incorrect handle position (T&T windows),
- standard microventilation in a corner (T&T windows),
- standard hardware is equipped with four anti-burglary bolts per sash,
- equipped with 3 gaskets,
- the hardware operates in a so-called dry chamber that provides longer service life,
- glazing with glass packages of up to 53 mm width,
- standard glazing package 4th/18Ar/4/18Ar/4th [Ug=0,5]*,
- available with a Classic-line,
- concealed hardware can be used,
- recommended for energy efficient construction.
*standard of the day 16.04.2019. Requires technological confirmation.
BluEvolution 82 system windows are equipped with standard 2-chamber glass packages with a very low heat transfer coefficient. The profiles are made of high-quality PVC, providing perfect thermal insulation guaranteed by a 6-chamber profile structure and triple sealing system. The installation depth of 82 mm allows you to use glass packages up to 53 mm wide. 2-chamber glass packages can be successfully installed. Using an insulating spacer enables you to achieve a heat transfer coefficient similar to those of passive windows.
Insulating spacers are made of complex insulating material, improving the insulation properties and reducing the risk of temporary condensation of water vapour. Moreover, they guarantee long-time air tightness of insulated glass panes and maximum reduction of heat loss.
If you wish to improve the heat comfort in the interior even more, you can install Climaplus 4S glass panes in your windows, a very innovative solution. A Climaplus 4S glass pane lets significantly less solar energy through, enabling you to maintain a pleasant temperature in the interior during summer and reduce costs of air conditioning.
The system combines innovative solutions for energy efficiency with a classic and attractive design. Available in a wide selection of colours, sandblasted and of wood structure. The windows are veneered on one side, two sides and in a duo-colour formula. Similarly to other Salamander systems, BluEvolution 82 is available with white, brown, and caramel core. What is more, anthracite core is an innovation. This is undoubtedly an asset, unavailable with any other system we offer.
It is worth mentioning that BluEvolution 82 windows are manufactured using V-Super technology. This way, we are able to offer the highest quality accurately finished joinery to our customers. The joint of the profiles becomes virtually invisible. The final effect is astonishing, especially on veneered windows.
Concealed hardware is a very practical and good-looking solution. In this case, all elements of the hardware are hidden in the fittings groove, invisible when the window is closed. Moving post rails, drive rods, hinges, and other functional elements can be hidden as well. This gives the window elegant appearance, balancing its composition. Apart from its aesthetic values, the concealed hardware has some practical advantages as well. It allows the user to adjust the sash in three dimensions and set the sash opening width.
The installation depth of BluEvolution 82 system windows and a robust steel reinforcement enable us to manufacture even very large structures while maintaining the highest safety standards. The profiles have additional stiffening – ribbing within the profile chambers.
However, safety depends on a number of factors. One of the most important is undoubtedly the appropriate selection of hardware. To produce BluEvolution 82, we employ Multi-Matic hardware, the best solution from Maco, a renowned Austrian manufacturer.
As a standard, the windows are equipped with four anti-burglary bolts per sash, anti-burglary pins with an adjustable clamp, and a device preventing incorrect handle position. An internal clamp is also a very important element of the system. It automatically adapts to the groove clearance. In addition to ensuring safety, it provides air tightness and easy operation of window sashes as well.
The safety class of windows may be increased. Using additional anti-burglary bolts, handles with a lock, and safety glass panes provides the best protection against burglars. We offer hardware that meets the requirements of WK1 and WK2 as well.
When choosing windows for single-family housing, it is a good idea to protect them against children. Our products can be equipped with a safety break in the handle that allows you to stop the opened sash in any position. So-called English tilt may also interest you. This safety device prevents windows from being opened, at the same time enabling the tilt function.
When selecting accessories for your windows, consider their functionality. We provide our customers with a variety of accessories that improve the aesthetics, comfort of use, and safety of the product.
We recommend a wide selection of outer roller blinds. They are produced using time-tested and well-known components, providing you with privacy and protection against weather conditions. We offer top-mounted and concealed adaptation roller blinds, depending on whether the house is being built or new joinery is being installed. Roller blinds produced by Beck+Heun, a renowned German manufacturer, are recommended for passive buildings.
If you are looking for effective protection against sunlight, screen-type outer blinds are a good choice and one of the most stylish ways to protect the premises against excessive heating. The material used for their production absorbs and reflects a large part of the sunlight, enabling the user to maintain a comfortable temperature inside the building. The roller blinds are available with an aluminium guide, wire guide, or an aluminium guide with a ZIP system. The material is a combination of glass fibre and PVC.
When selecting accessories, you must not forget about ventilators. They enable you to maintain proper air circulation in the interiors. We offer a wide range of pressure, humidity-sensitive, window-mounted, and pane-mounted ventilators.
