This roller shutter system enhances the thermal insulation and soundproofing performance while improving heating energy efficiency. The access hatch is installed on the front and its location is fixed. The complete installation trim perfectly conceals the roller shutter box from the outside. This makes the box a negligible obstruction to an aesthetic finish. This system can also be fitted with a roller insect blind on the roller shutter curtain exterior –– a very convenient upgrade for hot weather.

Shutter sections: Aluminium PU-foam filled sections or PVC sections; height: 37 mm to 52 mm,

Box form: square

Box design: PVC, size: 181x156, 206x181, or 245x220

with roller insect screen: 199x156, 224x181, or 263x220

Curtain type: aluminium or PVC

Access hatch: 1, in the front

Guide rails: aluminium or PVC

Installation anchor bolts: no

Weather-resistant: yes

Sound-proof: yes

Thermal insulation: yes

Drive: electric motor or manual gear

Roller insect screen: optional accessory, installed on the outside of the curtain

Cream white available for the length size of 155 cm and 180 cm.

Max. box width: 3000 mm
Min. box width: 500 mm
The width and height of the integrated roller insect screen is restricted.
